Top 10 Dry Pit Submersible Manufacturers for Water and Wastewater

Introduction

One of the most precarious scenarios for any municipal wastewater utility is the flooding of a dry pit pump station. In traditional designs utilizing standard TEFC (Totally Enclosed Fan Cooled) motors, a line break or seal failure that floods the dry well usually results in catastrophic motor failure, lengthy downtime, and expensive rewind or replacement costs. This vulnerability has driven a significant industry shift toward the specification of dry pit submersible pumps—units designed to operate in a clean, dry environment but built with IP68 submersible ratings to withstand accidental submersion.

For consulting engineers and utility directors, selecting the right equipment from the Top 10 Dry Pit Submersible Manufacturers for Water and Wastewater is not merely a matter of brand preference; it is a critical exercise in risk mitigation and lifecycle cost management. These pumps bridge the gap between the accessibility of dry-well pumps and the resilience of wet-well submersibles. They are predominantly used in large municipal lift stations, influent pump stations, and combined sewer overflow (CSO) management systems where flood resilience is mandatory but maintenance personnel require dry access.

However, the engineering challenge lies in the details. Unlike wet-well pumps that rely on the surrounding liquid for cooling, dry pit submersibles require sophisticated internal cooling systems to manage heat dissipation while running in air. Poor specification in this area can lead to overheating, premature stator insulation failure, and reduced bearing life. This guide sits within our coverage of submersible pump applications.

How to Select / Specify

When evaluating manufacturers and specific pump models, engineers must look beyond the initial purchase price. The complexity of dry pit submersible motors requires a multi-dimensional selection process.

Duty Conditions & Operating Envelope

• Continuous vs. Intermittent Duty: Unlike standard submersibles that may rely on a cool-down period, dry pit units are often rated for S1 (continuous) duty in air at full load. Specifications must explicitly require S1 capability without derating in a 40°C (104°F) ambient environment.
• Variable Frequency Drive (VFD) Turndown: When operating at reduced speeds, the internal cooling impeller (if equipped) produces less flow. The selected pump must be certified for the full range of the VFD (e.g., 30Hz to 60Hz) without overheating.
• Net Positive Suction Head (NPSH): In dry pit configurations, NPSH Available (NPSHa) is often limited by the physical elevation of the suction piping. Manufacturers must provide NPSH Required (NPSHr) curves with adequate safety margins (typically 3-5 ft) to prevent cavitation damage.

Materials & Compatibility

• Abrasion Resistance: For grit-heavy applications (influent stations), standard cast iron impellers may wear prematurely. Specifying high-chrome white iron to ASTM A532 (the correct designation, sometimes miswritten as AST A532) or proprietary hardened materials, commonly in the range of 55 to 60+ HRC, can extend impeller life substantially in gritty service.
• Corrosion Protection: While the pump is in a dry pit, the internal volute is exposed to corrosive wastewater. Furthermore, external coatings must withstand high humidity and potential submersion. Two-component epoxy coatings with a minimum thickness of 300-400 microns are standard.

Hydraulics & Process Performance

• Solids Handling: The “sphere size” specification is often insufficient. Modern ragging (wipes, fibrous materials) requires semi-open, chopper, or specifically designed “self-cleaning” impeller geometries.
• BEP Proximity: Pumps should be selected so the primary operating point is within 80% to 110% of the Best Efficiency Point (BEP). Operating too far left or right on the curve increases radial loads, deflecting the shaft and damaging mechanical seals—a critical failure mode in dry pit applications.

Installation Environment & Constructability

• Support Stands: Unlike frame-mounted pumps, these units typically rest on a suction elbow or a specialized stand. The structural engineer must account for the static weight and the dynamic forces generated during startup and operation.
• Suction Piping Geometry: To ensure uniform flow into the impeller eye, Hydraulic Institute Standards (HI 9.6.6) regarding straight pipe runs upstream of the suction must be strictly followed.

Reliability, Redundancy & Failure Modes

• Cooling System Architecture: This is a primary differentiator. Some manufacturers use the pumped media to cool the motor (open loop), while others use a self-contained glycol/water loop (closed loop). Closed-loop systems are generally preferred for raw wastewater to prevent clogging of cooling jackets.
• Seal Protection: Double mechanical seals are mandatory. The configuration (tandem vs. back-to-back) and the presence of a barrier fluid significantly affect MTBF (Mean Time Between Failures).

Controls & Automation Interfaces

• Stator Temperature Monitoring: PT100 sensors or thermal switches in each phase winding.
• Leakage Detection: Conductivity probes in the seal chamber (oil housing) and the stator housing (dry inspection chamber) to provide early warning of seal failure.
• Vibration Monitoring: For pumps above 50HP, integral vibration sensors compliant with ISO 10816 standards are recommended to detect imbalance or bearing wear remotely.

Maintainability, Safety & Access

• Service Entrances: Some designs feature a “swing-out” or “back-pull-out” capability, allowing the rotating assembly to be removed without dismantling the suction or discharge piping.
• Lifting Points: Certified lifting eyes must be positioned to maintain the center of gravity during hoisting, preventing damage to the mechanical seal surfaces during installation.

Lifecycle Cost Drivers

• Energy Efficiency: Specify motors with Premium Efficiency (IE3) or Super Premium (IE4) equivalents. The wire-to-water efficiency should be the primary evaluation metric.
• Maintenance intervals: Compare recommended oil change intervals and coolant inspection requirements. Closed-loop cooling systems typically require less invasive maintenance than open-loop systems prone to sediment buildup.

Comparison Tables

The following tables provide an engineering comparison of the leading manufacturers in this specific vertical.

Engineer & Operator Field Notes

Commissioning & Acceptance Testing

• Vibration Baseline: During SAT, establish a vibration baseline across the full VFD range. Dry pit pumps often exhibit resonance at specific frequencies due to the stiffness of the mounting stand. These “critical speeds” must be programmed out of the VFD logic (skip frequencies).
• Cooling Loop Verification: For closed-loop systems, visually verify the coolant level and ensure air has been bled from the jacket. Air pockets create hot spots that degrade insulation.
• Documentation: Ensure the O&M manual includes specific resistance values for the motor windings and sensor circuits.

Common Specification Mistakes

One of the most frequent errors in RFP documents is ambiguity regarding the “Dry Pit” definition. Engineers must specify whether the pump requires an external water source for cooling (undesirable in most municipal lift stations due to cross-connection risks) or if it must be self-contained.

Additionally, neglecting the cable management design is common. In a dry pit, heavy power cables hang from the ceiling or conduit drops. Without proper strain relief or Kellem grips, the weight of the cable puts tension on the cable entry gland, leading to water intrusion (wicking) into the motor terminal board.

O&M Burden & Strategy

• Coolant Inspection: Every 6 months, the internal coolant (typically water/glycol mix) should be checked for discoloration. Darkening indicates seal leakage allowing oil or wastewater into the cooling jacket.
• Seal Oil Analysis: Annual analysis of the barrier fluid (oil) is crucial. Presence of water indicates the lower mechanical seal is failing.
• Impeller Clearance: As wear rings or cutter plates erode, efficiency drops. Regular adjustment restores hydraulic performance and prevents recirculation cavitation.

Troubleshooting Guide

Symptom: High Stator Temperature Trips Possible Cause: Clogged cooling jacket (if open loop), air lock in coolant (if closed loop), or excessive starts per hour. Action: Check the cooling housing. If the pump utilizes pumped media for cooling, sediment may have settled in the jacket during a shutdown period.

Symptom: High Vibration Possible Cause: Ragging on the impeller causing imbalance, or “soft foot” where the mounting stand is not perfectly level. Action: Perform a pump reversal (if supported by controls) to clear rags. Check anchor bolt torque and shim the baseplate.

Design Details / Calculations

Sizing Logic & Methodology

1. Calculate Dynamic Head: Account for friction losses in the suction piping, which are often negligible in wet wells but significant in dry pits with check valves and elbows.
2. NPSH Calculation: NPSHa = P_atm + H_static_suction – H_friction_suction – P_vapor_pressure. Ensure NPSHa > NPSHr + 5ft margin. In retrofits, H_static_suction is often low, limiting pump selection to low-speed (4-pole or 6-pole) units to reduce NPSHr.

Specification Checklist

• Motor Enclosure: IP68 / NEMA 6P certified for continuous submersion (minimum 20 meters depth).
• Cooling: Closed-loop cooling system integrated into the motor housing.
• Cable Entry: Dual-seal cable entry with strain relief and separate terminal board compartment.
• Coatings: High-solids epoxy or ceramic coating suitable for immersion and atmospheric corrosion.

Standards & Compliance

• Hydraulic Institute (HI) 11.6: Standards for Submersible Pump Tests.
• NEMA MG1: Motors and Generators standards (specifically regarding insulation classes F or H).
• FM / UL Explosion Proof: Required where the space is classified as hazardous, Class 1 Division 1 or 2, Group D for methane. The classification is not automatic for dry pits: wet wells are routinely classified, while a dry pit with adequate ventilation and no direct opening to the wet well is frequently unclassified or Division 2. The authority having jurisdiction and the electrical engineer determine the classification for the specific station, and the pump specification should follow that determination rather than assume it.

FAQ Section

What is the difference between a dry pit pump and a dry pit submersible?

A traditional dry pit pump typically uses a standard TEFC motor which cannot be submerged. If the station floods, the motor fails. A dry pit submersible uses a watertight (IP68) motor designed to run in air but capable of surviving complete submersion without damage.

How does cooling work on a dry pit submersible pump?

Since air is a poor heat conductor compared to water, these pumps use an internal cooling system. Most utilize a “jacket” surrounding the stator. A coolant (glycol/water mix) is circulated through this jacket by a small internal impeller, transferring heat from the motor windings to the pumped liquid through the housing wall, or via an internal heat exchanger.

When should I select a dry pit submersible over a wet well submersible?

Dry pit submersibles are selected when operator access for maintenance is a priority or when retrofitting an existing dry pit station. They combine the ergonomic benefits of dry install with the flood resilience of a submersible. The wet-well alternative is covered in our guide to the submersible sewage pump, and the distinction between duty classes in our article on effluent vs sewage pumps.

What are the maintenance requirements for these pumps?

Routine maintenance typically includes monitoring vibration and temperature, continuously where instrumentation is fitted and otherwise at scheduled intervals. Physical maintenance involves checking seal oil quality and coolant levels annually, and greasing bearings (if not permanently lubricated) every 3,000-5,000 hours. Wet end inspections should occur annually or based on performance degradation.

Can I retrofit a standard dry pit pump with a submersible version?

Yes, this is a very common application. Manufacturers often provide “retrofit kits” or custom stands that match the suction and discharge flange centerlines of old pumps, minimizing the need for piping modifications.

How long do dry pit submersible pumps last?

With proper specification and maintenance, the typical lifecycle is 20-25 years. The mechanical seals and bearings are wear items, typically requiring replacement every 5-8 years depending on the severity of the service.

Conclusion

Selecting the right equipment is a balancing act between hydraulic efficiency, solids handling capability, and mechanical robustness. As municipalities face aging infrastructure and increased weather volatility, the dry pit submersible represents a logical evolution in pump station design.

Engineers should approach this selection by prioritizing the cooling system architecture and seal redundancy above brand loyalty. Broader selection context appears in our overview of submersible pumps in water management. For complex applications, always require a detailed lifecycle cost analysis (LCCA) that accounts for energy, maintenance intervals, and replacement parts over a 20-year horizon.
